Force H3X Hybrid 1Ph FH3X-8K-HY-1P

Brand	["Pylontech"]

Topology	transformerless
Max. short circuit current per MPPT (A)	25,0
Start input voltage (V)	80
Charging voltage (V)	102.4-409.6
MPP max. voltage range input (V)	550.00
Charging current (A)	40.00
Max. input voltage DC (V)	600.00
Number of independent MPPT (pcs)	3
Min. temperature ambient (°C)	-10
Contact for self-consumption optimization (e.g. for heat pump)	2
Surge protection AC	type 2
European efficiency (%)	97.50
Battery Connection	AC/DC
Display	w/o display
Max. efficiency (%)	98.00
MPP min. voltage range input (V)	80.00
Integrated DC switch	yes
Protection degree	IP55
Total number of string inputs	3
Surge protection DC	type 2
Max. output current (A)	34.80
AC nominal power (kW)	8.00
Backup system light	yes
Max. short circuit current (A) total	75.00
Integrated AC switch	no
Arc Fault Circuit Interrupter	yes
Max. generator power DC (kWp)	12.80
Decibel	29
Max. input current per MPPT (A).	16,0
Max. input current DC (A) total	48.00
Max. AC power (kVA)	8.00
