Description
The Solis S6 5kW Single-Phase Inverter is a next-generation solar inverter engineered for residential rooftop systems, offering high efficiency, robust safety, and smart connectivity. Equipped with dual MPPT, built-in DC isolator (DCI), and integrated Wi-Fi monitoring, this model is designed to deliver optimal performance, even in challenging conditions. Please note: Energy meter sold separately.
Key Features:
-
5kW AC Output Power: Perfect for residential solar installations with moderate to high energy demand.
-
2 MPPT Inputs: Maximizes energy yield from multi-orientation or partially shaded PV arrays.
-
Built-in DC Isolator (DCI): Enhances installation safety and reduces component costs.
-
Wi-Fi Connectivity: Real-time remote monitoring via SolisCloud platform or mobile app.
-
High Conversion Efficiency: Up to 98.1% for superior performance and savings.
-
Compact & Lightweight Design: Easy to install on indoor or outdoor walls (IP66 rated).
-
Future-Ready & Grid Compliant: Supports optional export limitation (with external meter) and smart grid features.
Description
| Brand | ["Solis"] |
|---|---|
| Rating (kW) | 5 |
| MPPT | |
| DC Switch | Yes |
| WiFi | w/ wifi |
| Use Application | Residential |
| Type | String |
| Phase | Single Phase |
| IP Rating | 66 |
| CEC Model | S6-GR1P5K-S (AS4777-2 2020) |
| Weight (kg) | 8.90 |
| Qty per Pallet | 24 |
| Pallet Weight (kg) | 265.16 |
| Dimension (L*W*H mm) | 330 * 371 * 161 |
| Pallet Dimension (L*W*H mm) | 1200 * 950 * 1050 |
